Grover AdditionstoInductanceFormulas 543 The first two terms ofthis equation will have to be calculated withagood dealof care, and asthe series involves odd powers of. Grover Inductance Calculations Pdf Files Microwaves101.com - A practical resource covering the fundamental principles of microwave design. Mutual inductance occurs when the change in current in one inductor induces a voltage in another nearby inductor.

(12)This formula is implemented in the following Open Office BASIC macro function:Function Mut(ByVal r1,r2,x) As Double' Calculate mutual inductance in microhenries between' two coaxial circular filaments' r1,r2 are radii of the respective loops in cm' x is the axial distance separating them in cma=sqr((r1+r2)^2+x^2)b=sqr((r1-r2)^2+x^2)c=a-bci=1cs=c.cdoao=(a+b)/2b=sqr(a.b)a=aoco=cc=a-bci=2.cics=cs+ci.c.cloop while c. Hence:x – Offset of the second coil with respect to the first coil;x 1, x 2 – Length of the respective coils;r 1, r 2 – Radii of the respective coils;p 1, p 2 – Winding pitch of the respective coils.N 1, N 2 – Number of windings of the respective coils.The following BASIC macro function calculates the mutual inductance between two coaxial solenoids having the dimensions and separation distance as shown in the above illustration.

Note that the offset can be less than the length of the coils. In that case, one coil would sit over top of the other, and the function will still calculate the correct mutual inductance.Function Mcoil(ByVal n1,r1,x1,n2,r2,x2,x) As double'Calculate mutual inductance of two coaxial solenoids' n1,n2=no. Of turns; r1,r2=coil radius; x1,x2=coil length;' x=offset of second coil along axis' All dimensions are in centimetersp1=x1/n1p2=x2/n2Msum=0.0for j1=0 to n1-1for j2=0 to n2-1z=j2.p2-j1.p1+xMsum=Msum+Mut(r1,r2,z)nextnextMcoil=Msumend functionThe program is quite straightforward, containing two nested loops: the outer loop for the turns of coil 1 and the inner loop for the turns of coil 2.

The pitch for each of the coils is calculated by dividing coil length by number of turns. These pitch values are multiplied by the respective loop counter variables j1 and j2 and combined with the coil offset distance x to find the distance between turns z. These values are then used as input to the Mut function. The variable Msum stores the total of all the mutual inductances.Next, we will look at using Mut to calculate the self inductance of a solenoid inductor. Self inductance of a coil can be calculated by adding up the mutual inductances between every pair of turns in the coil.

'Every pair' means each turn paired with every other turn in the coil. So a coil of N turns will have N 2 pairs of turns. However, many of the pairs are identical in that they are the same diameter and the same distance apart as other pairs of turns. For example, in a coil of 20 turns, the mutual inductance between turn 3 and turn 6 will be the same as the mutual inductance between turn 7 and turn 10, or any other pair of turns that are 3 turns apart. In general, for a coil of N turns, there will be 2 ×( N- m) pairs of turns that are spaced m × p apart, where p is the pitch. Therefore, we only need to calculate the mutual inductances N times rather than N 2 times, and then multiply each value by the appropriate factor for the number of times the pair occurs.

The factor of 2, in the expression for quantity of pairs, is present because we need to count the mutual inductance effect on turn i due to turn j, as well as the mutual inductance effect on turn j due to turn i, effectively doubling the number to be counted.There is one particular pair of turns which requires special attention. That is the case of a turn paired with itself. The mutual inductance between each turn and itself must be included in the total. To address this, we need to revisit the subject of geometric mean distances (GMD). It was stated earlier that the GMD between circles is equal to the distance between their centres only when the circles do not overlap.

In this one particular instance, the circles not only overlap, they are exactly superimposed. Fortunately, the references previously mentioned give the GMD values for the cases of superimposed figures, which is essentially the GMD of a figure from itself. In both of the above formulae, angles are in radians.It follows that r P = P/2 π, and r A =√( A/ π)It turns out that a coil enclosing the same area provides good results for most coils except extremely short ones. In fact, for infinitely long coils a circular coil enclosing the same area as the polygon will have exactly the same inductance. That is, for long coils the equivalent circular coil will have a radius r A. For extremely short coils, the equivalent circular coil is a weighted average of r A and r P. For a coil of zero length, then we can find that, empirically, the radius r E of the equivalent circular coil is approximately.

The error continues to decrease as shape factor ℓ C / D increases to values larger than 1, and also as N S increases.Polygonal Coil ExampleGrover gives an example in ref on page 60 for an octagonal coil of 50 turns of wire wound with a pitch of 0.4 cm. The diameter of the bare wire is 0.2 cm, and the diameter of the wire including its insulation is 0.25 cm. Calipered over opposite vertices of the octagon, the distance is 11.29 cm.Allowing for wire thickness, the diameter D of the circumscribed circle is 11.29−0.25=11.04 cm.
